Architectural Axonometric Perspective, Flats
An architectural axonometric drawing of designs for some residential flats, a commended submission for a competition organised by the Cement Marketing Company Ltd. Designed by architect R. Vaughan in conjunction with Clement Gilbin. The scheme provides four main blocks of six story maisonette flats
Picture No
13790109
Media ID
45159610
Size
5149px x 2989px
(4.8MB)
Credit
© CLM Archive Collection / Mary Evans
Source
Architectural design from Working Class Domestic Flats In Reinforced Concrete,' by R. Vaughan
Date
circa 1930s
Pick your License
Blocks Cement Clement Commended Conjunction Flats Maisonette Marketing Organised Provides Scheme Submission Vaughan
