Waltzing Matilda Driver's Compartment
This diagram shows the driver's compartment of a British WW2 Matilda infantry tank, pointing out various components and mechanisms including steering, gear and engine controls
Picture No
13809335
Media ID
45161315
Size
4003px x 3400px
(4.5MB)
Credit
© CLM Archive Collection / Mary Evans
Source
Diagram from Tanks Their Place In Modern Warfare,' probably by Bernard Venables
Date
1942
