Progress of Cotton, Bobbin & Drawing Frames

British 1840s depiction the Progress of Cotton, by Richard Barfoot, 5 of 12. After the cotton is carded, it is processed in the Bobbin and Drawing-Frames. At far left, long rolls of carded cotton are drawn between sets of metal rollers, then drawn together, and loaded into the tall metal can. The Bobbin-Frame, (third machine from left) receives the Cotton in the metal can after drawing; here it passes between rollers similar to the first set in the Drawing-Frame, as set of Spindles, twists the Cotton, turning it into a soft string, which wraps around large Bobbins about nine inches long. The Jack-Frame, (second from left) in the picture, then carries on the process by working the slightly twisted string finer and tighter, and running it on Bobbins of smaller size

Picture No

13125239

Media ID

45373663

Size

2700px x 2182px (1.7MB)

Credit

Mary Evans / The Everett Collection

Source

Courtesy Everett Collection

Date

1840s
