Drawing of Britain's first nuclear submarine
Jun. 06, 1959 - Layout Drawing of Britain's First Nuclear Submarine: An Admiralty artist's impression prepared to show the position of the main compartments in the nuclear submarine Dreadnought, which will be laid down at the Barrow-in-Furnace yard of Vickers-Armstrongs (Shipbuilders) Ltd today (June 12th). At Barrow-in-Furness, H.R.H. The Duke of Edinburgh is to lay the Keel - a prefabricated circular section of plating - of the Dreadnought, which will be the Royal Navy's first nuclear propelled submarine. The machinery to be installed will be similar to that fitted in the latest submarine of the Skip-jet class of the United States Navy. Key to Drawing: 1. Hydroplane 2. Torpedo tubes 3. Torpedo Compartment 4. Officers accommodation 5. Crew accommodation 6. Stores Compartments 7. Pump Compartment 8. Control Compartment. 9.Captain's Accommodation 10. Washplaces. 11.Galley 12. Battery Compartment 13. Reactor 14. Machinery Control compartment 15.Main Machinery compartments 16.Turbine gearing 17. Motor
