United Kingdom - Ireland

Mar. 03, 1967 - Commissioning Of Circulating Water Channel At The National Physical Laboratory Ship Division - Feltham. The new circulating water channel which has been built by the ministry of public building and works at Feltham was commissioned today by Vice-Admiral Sir Frank Mason. It is by far the largest installation of its kind in Europe. Its purpose is to permit the study of the flow of water around ship models and other bodies to take place in ideal conditions. The conventional model-towing tank has serious disadvantages in this respect observation of flow is difficult to arrange, and the steady running time at the higher speeds in limited inherently by the length of the tank. The now circulating water channel permits the model to be held stationery while the flow of water is directed past it in a smooth and precisely controlled manner. Es circulation of the water makes runs of unlimited time possible, while observation of the model can be made in ideal conditions through large windows provided in the working section of the channel. Photo Shows: A model of a tanker, representing 100, 000 - tons, fitted out for test of skin friction and distribution. The tubes from the model are attached to a 36-tube manometer for flow measurement

Picture No

13258223

Media ID

47041925

Size

4393px x 5528px (1.4MB)

Credit

Usage Restrictions

Editorial Use Only - No Property or Model Releases. For any non-editorial use, please contact Mary Evans direct

Source

Keystone Pictures USA
