Brooks Flexible Curve with instructions for use
Brooks flexible curve drawing tools for draughtsmen. These were made in a range of sizes from 8 to 24 inches. Brooks patented four types of flexible curve, patterns A to D. All have steel strips and brass linkage and retains the shape it is bent to
Picture No
11042161
Media ID
46894784
Size
6000px x 4004px
(4.8MB)
Credit
(c)Maurice Collins Images Collection /Mary Evans Picture Library
Source
Photograph of an original object in the Maurice Collins Collection
Date
circa 1910
