Sir George Cayley's drawings

Sir George Cayley's manuscript illustration of his 1849 Model Glider Design. From: C.H. Gibbs-Smith Sir George Cayley's Aeronautics 1796-1855 (London: HMSO/Science Museum. 1962) "Sketch of a model glider, with the rudder riding on the elevator also showing the wing curvature caused by the airflow: 1849."

1796 Airflow Caused Cayley Cayleys Curvature Elevator Gibbs Glider Hmso Rudder
