Sir George Cayley's drawings
Top: Design (end view) for a compound aeroplane, showing fixed wings dihedrally mounted low on the car, with flappers hinged to the sides of the car. Shown separately above is an alternate mounting for the flappers, on a pylon. circa 1849
Picture No
10839318
Media ID
48050831
Size
3014px x 4000px
(1.9MB)
Credit
© The Royal Aeronautical Society (National Aerospace Library) / Mary Evans Picture Library
Source
Photograph from The Royal Aeronautical Society Archive
