Cross section of a street in Berlin, around 1880

This engraving shows a cross-section of the subterranean layers of a street in Berlin around the year 1880, clearly showing various construction stages from different centuries, including the old street embankment, old cellar and filled-in casemate, and more recent sanitary and technical installations such as wells (Br.), hydrants (H.), gas pipes (Ga.), cables (K.), water pipes (W.) and drainage pipes (E. T.)

Restrictions Only for Canada and Curacao and United Kingdom and United States Of America

Cables Carts Casemate Cellar Centuries Clearly Cross-section Drainage Earthworks Embankment Hidden Hydrants Installations Layers Passers-by Pipes Recent Sanitary Sewer Sewerage Shaft Stages Subterranean Tramway
