Engine of a VW Beetle, 1938

View under the cowl of a VW Beetle: the middle part of the air-cooled four-stroke four-cylinder boxer engine with belt drive from alternator and fan. To the left is the ignition coil and above is the carburetor with the line to the fuel pump, to the right is the oil filler neck
