Diesel Fuel Injection Pump Testing
A technician tests a distributor fuel injection pump on a Hartridge machine at the CAV Engineering Centre in Acton, London. The distributor pump (foreground), is driven through a coupling by the test machine. The pump output at varying speeds can be recorded in the glass test tubes mounted in the panel. Photograph by Heinz Zinram
Picture No
10280987
Media ID
48372135
Size
3483px x 3963px
(1.8MB)
Credit
Mary Evans / Heinz Zinram Collection
Source
Photograph by Heinz Zinram
Date
1960s
