German ME262 Squirt Plane by G. H. Davis
Diagrammatic drawing of a German Messerschmitt ME262 jet fighter, used during the Second World War, showing its construction and propulsion unit
Picture No
10220238
Media ID
45988365
Size
6201px x 3914px
(4.4MB)
Credit
© Illustrated London News Ltd/Mary Evans
Source
Illustration by George Horace Davis in The Illustrated London News', 5 May 1945, p494
Date
1945
