Hawker Hurricane Fighter 1939

Diagram illustration of a British Hawker Hurricane Fighter, able to fly at a height of 35, 000 feet, with a 600 mile range and eight fixed Browning guns, firing 250 rounds in 10 seconds, controlled by the fighter pilot. The structural skeleton is all of metal, fabric covered and all three wheels are retracted when flying

Diagram Diagrams Hurricane Structural
