Height of the double bottom on a great liner
Our sinkable ships: how far they are protected at the present time. The height of the double bottom in a great liner: 5 ft 3 in. An engineer's assistant of average height can walk through the openings if he slightly stoops. The method of fixing the bottom plates is shown, also the intercostal girders which extend completely fore and aft and immensely strengthen the ship. The double bottom is utilised for carrying water ballast
Picture No
13564411
Media ID
46788595
Size
4114px x 2707px
(4.6MB)
Credit
© Illustrated London News Ltd/Mary Evans
Source
Illustration in The Sphere, 11th May 1912, p120
Date
1912
Pick your License
Ballast Cross-section Diagram Diagrammatic Girder Intercostal Liners Protected
