Section of the Thames Embankment

A section of the Thames Embankment, taken by the Charing Cross railway bridge, showing; (1) the subway, designed to hold the gas pipes, the water pipes, perhaps the telegraph wires, (2) the low level sewer, (3) Metropolitan and District Railway and (4) the tubular structure through which the pneumatic railway is to proceed from Charing Cross, under the bed of the Thames, towards the Waterloo Road Station of the Southwestern Railway

Charing Cross-section Cut-away Cutaway Diagram Embankment Level Mar21 Pneumatic Sewer Subway
