Engraving depicting a sectional view of the armature

Engraving depicting a sectional view of the armature of Edison's 5 hp generator for electric light. A: wooden cylinder mounted on shaft, attached to B: soft iron plates, and wound the soft iron wire, D. C, C. are vulcanized fibre disks, E. coils of cylinder and connected to copper bars, F, of the commutator cylinder, G

Armature Coils Connected Cylinder Disks Edison Fibre Generator Sectional Shaft Soft Wound
