Rag-and-chain pump being used to raise water from

Rag-and-chain pump being used to raise water from a mine. Two men are turning the drive-shaft on which is mounted a spur gear which transfers power to the pump by means of a lantern, D. Apart from the chain connecting the rags, almost all the material used in the mechanism is wood. From De re metallica, by Agricola, pseudonym of Georg Bauer (Basle, 1556). Woodcut

Restrictions Only for Ireland and United Kingdom

1556 Agricola Apart Basle Bauer Connecting Means Mechanism Metallica Pseudonym Rag-and-chain Rags Raise Spur Switzwerland Transfer Transfers Turning
