: Ventilating a mine. (Basle, 1556). Woodcut


Ventilating a mine. (Basle, 1556). Woodcut

Ventilating a mine. Hollow drum with air holes, B, at opposite sides, mounted on an axle, C, to which are fixed fans rotating inside the drum. Axle turned by water wheel through a spur gear and lantern. When axle turned, the fans rotating inside the drum would suck air in one hole and out of the opposite one, setting up a current of air. From De re metallica, by Agricola, pseudonym of Georg Bauer (Basle, 1556). Woodcut

Picture No
13901181
Media ID
48387889
Size
2325px x 2430px (907KB)
Credit
World History Archive / Mary Evans Picture Library
Source
World History Archive

Pick your License

Please tell us the book title or ISBN

Please supply intended use




Restrictions Only for Ireland and United Kingdom

1556 Agricola Axle Basle Bauer Current Fixed Holes Hollow Metallica Opposite Pseudonym Rotating Spur Suck Ventilating
