John Smeaton's water gin winding engine, 19th century

John Smeaton's water gin winding engine, 19th century.. John Smeaton's design for a water gin (winding engine) for drawing coals from the pits, 19th century. Copperplate engraving by W. Lowry after an Illustration by J. Farey from Abraham Rees Cyclopedia or Universal Dictionary, London, 1817

1817 Coals Cyclopedia Dictionary Farey Lowry Pits Rees Winding
