Plans and sections of ancient churches

Plan of subterranean catacombs 1, plan of an ancient church from Palladio 2, plan of the ancient St Peter's at Rome 3, plan 4 and section 5 of Sancta Sophia at Constantinople, plan of St Mark's at Venice 6, section of the Church of St Mary of Flowers at Florence 7

1785 Charles Taylor Draughtsman Elevation Francis Fitzgerald Palladio Stipple
