Inside a British submarine by G. H. Davis
Inside a British submarine: complex details of the craft in which our underwater crews live and fight'. A sectional view of a boat of the T class, showing how machinery, torpedoes, fighting gear and living quarters are compressed into a craft housing more than 50 men
Picture No
10511514
Media ID
46042871
Size
6000px x 4174px
(4.2MB)
Credit
© Illustrated London News Ltd/Mary Evans
Source
Illustration by George Horace Davis in The Illustrated London News', 24 April 1943, pp458-9
Date
1943
Pick your License
Compressed Crews Diagram Horace Quarters Sectional Spread Submarines Torpedoes
