Colt Pistol, US Patent Diagram
As Samuel Colt originally envisioned his repeating pistol in the patent drawing above, it was to have chambers for 10 cartridges. Other changes, including raising the caliber from 34 to.44, were suggested by a texas ranger, Sam Walker
