Diagonal Steam Engine, 19th Century

Diagonal steam engines had sloping, upward-pointing cylinders. They were usually used as a means of driving a paddle wheel shaft, while keeping a low center-of-gravity. Some used paired cylinders as Brunel's triangle engine. A few were land based, most were marine
