Supersonic Aircraft Shockwaves, Schlieren Image

Colorized image of a Northrup T-38 Talon supersonic jet breaking the sound barrier. This image was captured during Air-to-Air Background Oriented Schlieren flights, or AirBOS, which took place at NASAaEURTMs Armstrong Flight Research Center in Edwards, California. The flight series tested an upgraded imaging system capable of capturing high-quality images of shockwaves, rapid pressure changes which are produced when an aircraft flies faster than the speed of sound, or supersonic. Shockwaves produced by aircraft merge together as they travel through the atmosphere and are responsible for what is heard on the ground as a sonic boom
