Proposed Gravesend to Tilbury Fort Tunnel
Plan of the proposed Gravesend to Tilbury Fort Tunnel, showing the section under Rotherhithe, London, by ?Ralph Dodd. The tunnel was proposed by Ralph Dodd in 1799, but abandoned in 1802 due to water ingress. Engraving on paper, sectioned and mounted onto linen
Picture No
14154437
Media ID
45958023
Size
10004px x 3394px
(5.1MB)
Credit
© The Geological Society / Mary Evans
Source
Geological Society of London. Archive reference: LDGSL/441 - Image reference: 08-07
Date
1799-1802
Pick your License
1799 1802 Dodd Eighteenth Gravesend Ingress Linen Onto Proposed Rotherhithe Sectioned Tilbury
